CROSSFIRE Trex 110

Size:

110cc

Details:

COLOUR: Blue, Green, Pink

he Crossfire Trex 110 is small medium youth ATV. Its one of our best looking quads and the first machine to utilise LED lighting and full time day time running lights (DRL).

Fully automatic transmission and electric start means easier for kids to jump on and of machine without the need for kicking.

The Trex has fully enclosed foot wells so the rider stays dryer and more protected than pegs alone.

The memory foam seat is both plush and grippy for hours of riding.


Trex 110 Included Features:

110cc 4 stroke
Electric Start
Enclosed Foot boards
7” wheels
LED Lights
DRL
Air Box

Specifications
Engine 152FMH
Clutch Type Wet multichip + automatic centrifugal
Measured Flow Capacity 107ml
Rated Load Quality 60kg
Carburetor Plunger PZ19
Compression Ratio 9.1:1
Cylinder Diameter x Stroke 52.4 x 49.5 mm
Transmission Chain Drive
Ignition CDI
Starter Electric
Gearshift Fully Automatic
Max Power / Relative Speed 5.0/7500kW (r/min)
Max Torque / Relative Speed 7.5/5500N.m (r/min)
Suspension / Brakes / Tyres
Suspension Front Single Rocker Independent Suspension
Suspension Rear Single Longitudinal Arm Independent Suspension
Shock Absorber Front 185mm
Shock Absorber Rear 260mm
Brakes Front Drum Brake
Brakes Rear Disc Brake
Tyres Front Size and Spacing 16*8.00-7, 630mm
Tyres Rear Size and Tread 16*8.00-7, 580mm

Dimensions
Seat Height 620mm
Chassis Height 150mm
Handle Height 820mm
Minimum Turning Diameter 2800mm
Braking Manipulation (Front/Rear) Front and rear handbrake
Net Weight 90kg
Minimum Ground Clearance 95mm
Wheelbase 850mm
Max Speed 45km/h
Vehicle Size 1260 x 820 x 855 mm
Battery 12V, 5AH
Fuel Grade 90# or above
Fuel Capacity 5L

Other
Lubrication Mode Pressure and Splash Mixed Lubrication
Lubrication Oil Brand 15W/40-SE (-10-40 C) HQB-10 (<-10 C)

Warranty
6 months up to 12 months* *If 1 month and 6 months services have been done by a Crossfire Dealer – warranty is extended to 12 months for vehicles up to 250cc. Please make sure you have proof of services.
