South Pacific 900E - Horizontal Pro 900 Series - Suits Boats to 13.5mts.,

Material:

Up/down switch, Solenoid, Circuit breaker, hardware
Template, User manual

Details:

With a maximum working load of 275kg and swift retrieval speeds, it's sure to do the job next time your out boating.

It comes with a standard stainless steel gypsy, which takes both rope and chain, ideal for customization to your individual needs.

The electric brake on the gypsy enables you to terminate the anchor fall at any time and hold the anchor.

With new attributes such as the built-in torque limiter and additional stainless steel parts, it proves to provide smoother and more reliable operation.


The stainless steel Gypsy takes both rope and chain.

The tremendous lifting capacity and fast retrieval speed are provided by a heavy duty DC motor.

3 years warranty.

PACKAGE CONTENTS
Up/down switch, Solenoid, Circuit breaker, hardware
Template, User manual

900Express
-- Operating Voltage : 12V DC only

-- Max Working Load : 320 kg (700lb)

-- Typical Working Load : 60 kg (132 lb)

-- Retrieval Speed : 30 m(100ft)/min

-- Pay-Out Speed : free fall or 36 m/min (120 ft/min)

-- Current Draw (Typical) : 32 amp(12V)

-- Motor Type / Efficiency : permanent magnet / 82 %

-- Motor Wattage I/O : 1100W / 450W

-- Gear Type / Efficiency : spur gear / 92%~98%

-- Dimension (LxWxH) : 304 mm x 197 mm x 153mm

-- Weight : 9.2 kg (20.4lb)

-- Suit Chain Size :, 8mm short link

-- Suit Rope Size : 12, 14mm (selectable)

-- Suit Deck Thickness : 3mm~60mm

900Mighty
-- Max Working Load : 500 kg (1100lb)

-- Typical Working Load : 90 kg (200lb)

-- Retrieval Speed : 18 m(60ft)/min

-- Pay-Out Speed : free fall or 19 m/min (63 ft/min)

FEATURES
-- Efficient spur gears, low current draw, high output power

-- Efficient heavy duty DC motor produce less heat

-- Stainless steel Gypsy takes both rope and chain

-- A torque limiter to deliver smoother operation and greater reliability

-- Switch controls automatic free fall

-- Selectable free fall or power out mode

-- Compact one-piece housing ensure water resistance

-- Simple deck mounting with no under deck parts

When you deal with Precision Marine you get personalized service where you can email or phone us direct before purchase and speak to someone who knows.
