A VIPER To Suit Your Boat

Click Image to Enlarge

Details:

Viper “S” Series GRAVITY FEED 1000W All Stainless Winch Bundle 183m Rope & Chain Kit Plus Much More.

- 1000W Submersible Stainless Steel Electric Motor with IP68 Certification
- 28mm Solid S/S Shaft With 3 Support Bearings
- 8mm Marine Grade 316 Plate S/S Hand Polished to a Mirror Finish
- Viper 316 Stainless Steel Marine Worm Drive Gear Box
- 360 Degree Motor Rotation with 16 Different Positions
- Max fall rate: 138mtrs per minute
- Max Retrieval rate: 45 mtrs per minute
- Suit Vessel Length: 5.7 mtrs +
- Weight: 23 kgs (winch only)
- Well Clearance Required: Width 435mm x depth 365mm x height 266mm

Part No. 30072-5S

RRP AUD $2,245.00

Viper GRAVITY FEED “S” Series Free Fall 1000W All Stainless Steel Submersible Winch Bundle Includes 165m 5mm Hi-Spec Rope with 10m shock cord and 8mtrs Of 6mm Short Link Gal Chain And Now Includes 316
==============================
Viper “S” Series GRAVITY FEED 1000W All Stainless Winch Bundle 98m Rope & Chain Kit Plus Much More.

-1000W Submersible Stainless Steel Electric Motor with IP68 Certification
- 28mm Solid S/S Shaft With 3 Support Bearings
- 8mm Marine Grade 316 Plate S/S Hand Polished to a Mirror Finish
- Viper 316 Stainless Steel Marine Worm Drive Gear Box
-360 Degree Motor Rotation with 16 Different Positions
- Max fall rate: 138mtrs per minute
- Max Retrieval rate: 45 mtrs per minute
-Suit Vessel Length: 5.7 mtrs +
- Weight: 23 kgs (winch only)
- Well Clearance Required: Width 435mm x depth 365mm x height 266mm

Part No. 30072-6S

RRP AUD $2,095.00

Viper “S” Series GRAVITY FEED Free Fall 1000W All Stainless Steel Submersible Winch Bundle Includes 90m 6mm Double Braid Rope Spliced To 8mtrs Of 6mm Short Link Gal Chain
==============================
Viper “S” Series MICRO 1000 All Stainless Steel Winch Bundle Inc 60m Rope & Chain Kit Plus Much More.

- 1000 Watt Stainless Steel Submersible Electric Motor with IP68 Certification
-All New 316 Stainless Steel Marine Grade Worm Drive Gearbox
-28mm Solid S/S Shaft With 3 Support Bearings
-8mm Marine Grade 316 Plate S/S Hand Polished to a Mirror Finish
- 360 Degree Motor Rotation 16 Different Positions
- 1 Mtr of 3 B&S Tinned Copper Cable Fitted & Leak tested
- Max fall rate: 45mtrs per minute
- Max retrieval rate: 40mtrs per minute
- Suit vessel length: 4 mtrs +
-Weight: 15kgs

Part No. 30038-6S

RRP AUD $1,489.00

Viper “S” Series MICRO 1000W All Stainless Steel Submersible Winch Bundle – One Of The World’s Most Powerful Winch For Its Size
==============================
Viper “S” Series MICRO 1000W All Stainless Steel Winch Bundle 100m HiSpec Rope & Chain Kit Plus Much More.

- 1000 Watt Stainless Steel Submersible Electric Motor with IP68 Certifification
- All New 316 Stainless Steel Marine Grade Worm Drive Gearbox
- 28mm Solid S/S Shaft With 3 Support Bearings
- 8mm Marine Grade 316 Plate S/S Hand Polished to a Mirror Finish
- 360 Degree Motor Rotation 16 Different Positions
- 1 Mtr of 3 B&S Tinned Copper Cable Fitted & Leak tested
- Max fall rate: 45mtrs per minute
- Max retrieval rate: 40mtrs per minute
- Suit vessel length: 4 mtrs +
- Weight: 15kgs

Part No. 30038-4S

RRP AUD $1,595.00

Viper “S” Series MICRO 1000W All Stainless Steel Submersible Winch Bundle – One Of The World’s Most Powerful Winch For Its Size
==============================
Viper “S” Series RAPID 1000 All Stainless Winch Bundle 100m Rope & Chain Kit Plus More.

-1000W Submersible Stainless Steel Electric Motor with IP68 Certification
-28mm Solid S/S Shaft With 3 Support Bearings
-8mm Marine Grade 316 Plate S/S Hand Polished to a Mirror Finish
-Viper 316 Stainless Steel Marine Worm Drive Gear Box
-360 Degree Motor Rotation with 16 Different Positions
-Max fall rate: 50mtrs per minute
-Max Retrieval rate: 45 mtrs per minute
-Suit Vessel Length: 5.7 mtrs +
-Weight: 17 kgs (winch only)
-Well Clearance Required: Width 395mm x depth 410mm x height 260mm

Part No. 30021-6S

RRP AUD $1,595.00

Viper “S” Series RAPID 1000W with a Stainless Steel Marine Gearbox. This Winch Bundle Includes 100m Double Braid Rope Spliced To 8mtrs Of 6mm Short Link Gal Anchor Chain
==============================
Viper “S” Series RAPID 1000W All Stainless Winch Bundle + 200m Rope & Chain Kit Plus Much More.

-1000W Submersible Stainless Steel Electric Motor with IP68 Certification
-28mm Solid S/S Shaft With 3 Support Bearings
- 8mm Marine Grade 316 Plate S/S Hand Polished to a Mirror Finish
- Viper 316 Stainless Steel Marine Worm Drive Gear Box
-360 Degree Motor Rotation with 16 Different Positions
-Max fall rate: 50mtrs per minute
Max Retrieval rate: 45 mtrs per minute
-Suit Vessel Length: 5.7 mtrs +
-Weight: 17 kgs (winch only)
- Well Clearance Required: Width 395mm x depth 410mm x height 260mm

Part No. 30021-5S

RRP AUD $1,799.00

Viper “S” Series RAPID 1000W All Stainless Steel Submersible Winch Bundle Includes 200MTRS Hi Spec 3000 Rope Spliced to a 10mtr 3 Strand Shock Cord D Shackled to 8mtrs of 6mm Short Link Gal Chain
==============================
Viper “S” Series RAPID 1000W All Stainless Winch Bundle 75m Rope & Chain Kit Plus Much More.

- 1000W Submersible Stainless Steel Electric Motor with IP68 Certification
- 28mm Solid S/S Shaft With 3 Support Bearings
- 8mm Marine Grade 316 Plate S/S Hand Polished to a Mirror Finish
- Viper 316 Stainless Steel Marine Worm Drive Gear Box
- 360 Degree Motor Rotation with 16 Different Positions
- Max fall rate: 50mtrs per minute
- Max Retrieval rate: 45 mtrs per minute
- Suit Vessel Length: 5.7 mtrs +
- Weight: 17 kgs (winch only)
- Well Clearance Required: Width 395mm x depth 410mm x height 260mm

Part No. 30021-8S

RRP AUD $1,595.00

Viper “S” Series RAPID 1000W All Stainless Steel Submersible Winch Bundle Includes 75m 3 Strand Rope Spliced To 8mtrs Of 6mm Short Link Gal Chain
==============================
Viper Pro Series II 1500W Anchor Winch Kit Inc 100m Rope & Chain Plus Much More.

- Max fall rate: 50mtrs per minute
- Max retrieval rate: 46mtrs per minute
- Suit vessel length: 8 mtrs +
- Max load: 360kgs
- Weight: 28kgs

Part No. 30003-8

RRP AUD $1,749.00

Viper Pro Series II 1500W Winch Bundle – More Power, More Torque, More Speed & More Value
===============================
Viper Pro Series II 1500W Winch Bundle Inc 200m Rope & Chain Kit Plus More.

-Max fall rate: 50mtrs per minute
- Max retrieval rate: 46mtrs per minute
- Suit vessel length: 8 mtrs +
-Max load: 360kgs
-Weight: 28kgs

- Max fall rate: 50mtrs per minute
- Max retrieval rate: 46mtrs per minute
- Suit vessel length: 8 mtrs +
- Max load: 360kgs
- Weight: 28kgs

Part No. 30003-6

RRP AUD $1,799.00

Viper Pro Series II 1500 Winch Bundle ……FAST RELIABLE AND BUILT TO LAST!
===============================
